    255 x 125 Square Channel RK3050000

    SKU: CSS0090-00023
    Marshalls uses hydraulic pressing in the manufacture of its standard natural kerb, channels and edgings. The result is the durability and consistent long-term performance you would expect from Marshalls with a functional unit of this type. These precision-manufactured products are available in many different shapes and profiles to fulfil a wide range of design requirements. Bullnose and Square channels are typically used as a spacer between the kerb and the carriageway or for off road parking and lay-bys, while Dished channels provide an aid to drainage. Bullnose, Round Top and Flat Top edging is mostly used along footpath edges.
    Availability: In stock
    €18.47
    i h
    Ship to
    *
    *
    Shipping Method
    Name
    Estimated Delivery
    Price
    No shipping options
    NOTE: The weight of this item exceeds our standard delivery limit. Please contact us for the delivery costs and time!



    Marshalls uses hydraulic pressing in the manufacture of its standard natural kerb, channels and edgings. The result is the durability and consistent long-term performance you would expect from Marshalls with a functional unit of this type.

    These precision-manufactured products are available in many different shapes and profiles to fulfil a wide range of design requirements.

    Bullnose and Square channels are typically used as a spacer between the kerb and the carriageway or for off road parking and lay-bys, while Dished channels provide an aid to drainage. Bullnose, Round Top and Flat Top edging is mostly used along footpath edges.



    Appearance  Solis unit with pimple surface
    Manufacturing Process Hydraulically pressed concrete
    Base Raw Material Concrete
    Governing Manufacturing Standards All data where relevant to be established in accordance with BS EN 1340 : 2003
    CE Marking/DOP https://www.marshalls.co.uk/dop
    NBS Specification Q10 10



    PHYSICAL PROPERTIES

    Work Dimensions (mm) 255 x 125 x 915
    Tolerances on Work Dimensions (mm) Length ±3mm, width ±3mm,
    thickness ±3mm
    Abrasion Resistance (mm) ≤ 23mm (Wide Wheel Abrasion Test)
    Durability (Freeze-thaw) ≤ 1.0 kg/m² as a mean with no individual value > 1.5 kg/m²
    Material Density 2300 kg/m³ (typically)
    Slip/Skid Resistance (polished) Mean polished skid resistance value (PSRV) : > 45
    Slip/Skid Resistance (unpolished) Mean unpolished skid resistance value (USRV) : > 45.
    Transverse/FlexuralSplit/Breaking Characteristic bending strength of 3.5 MPa with no individual result less than 2.8 MPa



    SPECIFICATION

    Approx unit weight (kg) 64
    Emission of Asbestos No content
    External Fire Performance Deemed to satisfy. See commission decision 2000/553/ECU
    Reaction to fire  Class A1, see commisson decision 2000/605/EC



    APPLICATION

    Suitability Laid in accordance with BS 7533-6 : 1999



    FURTHER INFORMATION

    Cleaning & Maintenance Information regarding the cleaning & maintenance of this product may be obtained on request
    Efflorescence Any product containing cement during its early life may exhibit a temporary white discolouration known as efflorescence. This is not a product fault and will gradually disappear with exposure to natural weathering and trafficking
    Weathering It should be appreciated that with all products weathering and site conditions can cause shade variation to appear across the surface of individual units. This does not in any way affect the performance of the units and any such variation will diminish over a period of time as the product matures.
    Product Evolution The evolution of new product design is continuous and information is subject to change without notice. Customers should check with the supplier to ensure that they have the latest details. Marshalls reserve the right to amend the technical information as deemed necessary and in accordance with the relevant national and international standards without
    notice
    Contact Us For technical information on the design, specification and construction when utilising the product, contact the Technical Advisory Services Department on 0370 411 2233
    *
    *
    *
    *
