Classic Screw PZ3 CSK - BZP 6.0 x 100 100 PCS

Pack Type: Box

Pack Quantity: 100 Pieces

Barcode: 5055017507580

• Double countersunk reduces the likelihood of head shear and assists completion of countersinking
• Patented lubrication, designed to enhance screw insertion time and provides greater resistance to corrosion
• 40° deep single thread to provide a secure fixing with high pull-out resistance
• Surface hardened up to 750 HV to prevent torque shearing under load and a core hardness of up to 450 HV for improved ductility
• Single slash on 25mm+ to reduce torque and the likelihood of the timber splitting when the screw is inserted close to the edge
• All sizes up to and including 75mm are fully threaded and lengths 80mm and above all have 70mm thread length

Product Specifications

MOQ Increment	1
MOQ	1
Thread L (mm)	70
Point Type	25° Sharp with Single Slash
Lubrication	Gleitmo
Thread Ø (mm)	6
Head Type	Double Countersunk
Packs per Carton	15
Substrates	Hardwood, Softwood, Chipboard, MDF, Plastic, Thin Sheet Metal
Corrosion Rating (1-5)	2 - Occasionally damp/wet, rural and sheltered areas
Material	Carbon Steel
Finish	Zinc & Yellow
Driver Bit Size	PZ3
Inner Thread Ø d1 (mm)	3.8
Size (mm)	6.0 x 100
L (mm)	100
Pack Qty	100
Pack Type	Box
Recess Type	Pozi
Thread Type	Single Coarse 40°
Feature 3	40° deep single thread to provide a secure fixing with high pull-out resistance
Feature 5	Single slash on 25mm+ to reduce torque and the likelihood of the timber splitting when the screw is inserted close to the edge
Feature 4	Surface hardened up to 750 HV to prevent torque shearing under load and a core hardness of up to 450 HV for improved ductility
Feature 2	Patented lubrication, designed to enhance screw insertion time and provides greater resistance to corrosion
Feature 1	Double countersunk reduces the likelihood of head shear and assists completion of countersinking
Feature 6	All sizes up to and including 75mm are fully threaded and lengths 80mm and above all have 70mm thread length
Brand	TIMCO
Thread Coverage	Partially Threaded
