Barcode: 5055017507566
• Double countersunk reduces the likelihood of head shear and assists completion of countersinking
• Patented lubrication, designed to enhance screw insertion time and provides greater resistance to corrosion
• 40° deep single thread to provide a secure fixing with high pull-out resistance
• Surface hardened up to 750 HV to prevent torque shearing under load and a core hardness of up to 450 HV for improved ductility
• Single slash on 25mm+ to reduce torque
and the likelihood of the timber splitting when the screw is inserted close to the edge
• All sizes up to and including 75mm are fully threaded and lengths 80mm and above all have 70mm thread length
Product Specifications
Recess Type | Pozi |
Packs per Carton | 12 |
Head Type | Double Countersunk |
Thread Type | Single Coarse 40° |
Substrates | Hardwood, Softwood, Chipboard, MDF, Plastic, Thin Sheet Metal |
Corrosion Rating (1-5) | 2 - Occasionally damp/wet, rural and sheltered areas |
Pack Type | Box |
MOQ | 1 |
Material | Carbon Steel |
Driver Bit Size | PZ3 |
Inner Thread Ø d1 (mm) | 3.8 |
L (mm) | 80 |
Thread L (mm) | 70 |
Point Type | 25° Sharp with Single Slash |
Pack Qty | 200 |
Size (mm) | 6.0 x 80 |
MOQ Increment | 1 |
Lubrication | Gleitmo |
Thread Ø (mm) | 6 |
Finish | Zinc & Yellow |
Feature 2 | Patented lubrication, designed to enhance screw insertion time and provides greater resistance to corrosion |
Feature 5 | Single slash on 25mm+ to reduce torque and the likelihood of the timber splitting when the screw is inserted close to the edge |
Feature 4 | Surface hardened up to 750 HV to prevent torque shearing under load and a core hardness of up to 450 HV for improved ductility |
Feature 1 | Double countersunk reduces the likelihood of head shear and assists completion of countersinking |
Brand | TIMCO |
Feature 3 | 40° deep single thread to provide a secure fixing with high pull-out resistance |
Feature 6 | All sizes up to and including 75mm are fully threaded and lengths 80mm and above all have 70mm thread length |
Thread Coverage | Fully Threaded |
