Barcode: 5055017563104
All steel, non-flammable fixing conforming to BS 7671 standard's 18th edition, which requires wiring systems to be supported by materials which are unlikely to prematurely collapse in the event of a fire.
TECHNICAL DATA
Concrete ≥25N/mm2
Drill Hole Ø (mm) : 12.0
Min. Embed. Depth (mm) : 40
Min. Drill Hole Depth (mm) : 40
Rec. Tensile Load (kN) : 4.65
Max. Rec. Load (kg) : 465
Min. Centre Spacing (mm) : 120
Min. Edge Distance (mm) : 120
Min. Structure Thickness (mm) : 100
Concrete 25N/mm2
Rec. Tightening Torque (Nm) : 7
Product Specifications
Pack Dimensions L x W x H (mm) |
132 x 46 x 70 |
Fixture Hole Size Ø (mm) |
12 |
Packs per Pallet |
816 |
Min. Drill Hole Depth (mm) |
40 |
Approval |
BS 7671:2018 |
Drill Hole Ø (mm) |
12 |
Thread Ø x L (mm) |
M10 x 40 |
Anchor L (mm) |
40 |
Thread Ø (mm) |
M10 |
Pallet Qty (pcs) |
40800 |
Pack Weight (kg) |
1.099 |
Pack Type |
Box |
Material |
Carbon Steel |
MOQ Increment |
1 |
Packs per Carton |
12 |
Pack Qty |
50 |
Type |
Not Lipped |
Substrates |
Concrete |
Finish |
Zinc |
MOQ |
1 |
Thread L (mm) |
15 |
Thread Type |
Metric |
Corrosion Rating (1-5) |
1 - Clean, dry & low humidity environments |
Feature 1 |
All steel, non-flammable fixing conforming to BS 7671 standard's 18th edition, which requires wiring systems to be supported by materials which are unlikely to prematurely collapse in the event of a fire. |
Brand |
TIMCO |
