Barcode: 5055017563111
• All steel, non-flammable fixing conforming to BS 7671 standard's 18th edition, which requires wiring systems to be supported by materials which are unlikely to prematurely collapse in the event of a fire.
TECHNICAL DATAConcrete ≥25N/mm2
Drill Hole Ø (mm) : 16.0
Min. Embed. Depth (mm) : 50
Min. Drill Hole Depth (mm) : 50
Rec. Tensile Load (kN) : 9.35
Max. Rec. Load (kg) : 935
Min. Centre Spacing (mm) : 150
Min. Edge Distance (mm) : 150
Min. Structure Thickness (mm) : 125
Concrete 25N/mm2
Rec. Tightening Torque (Nm) : 16
Product Specifications
Finish |
Zinc |
Thread Type |
Metric |
Min. Drill Hole Depth (mm) |
50 |
Corrosion Rating (1-5) |
1 - Clean, dry & low humidity environments |
Thread Ø x L (mm) |
M12 x 50 |
Material |
Carbon Steel |
Thread Ø (mm) |
M12 |
MOQ Increment |
1 |
Packs per Carton |
6 |
Pack Qty |
50 |
MOQ |
1 |
Anchor L (mm) |
50 |
Thread L (mm) |
20 |
Approval |
BS 7671:2018 |
Fixture Hole Size Ø (mm) |
14 |
Pallet Qty (pcs) |
16200 |
Pack Weight (kg) |
2.571 |
Pack Type |
Box |
Drill Hole Ø (mm) |
16 |
Substrates |
Concrete |
Pack Dimensions L x W x H (mm) |
182 x 82 x 60 |
Type |
Not Lipped |
Packs per Pallet |
324 |
Feature 1 |
All steel, non-flammable fixing conforming to BS 7671 standard's 18th edition, which requires wiring systems to be supported by materials which are unlikely to prematurely collapse in the event of a fire. |
Brand |
TIMCO |
